Subway® Ultra-Lite Bass Cabinets 1x12
Full Details
SUBWAY® ULTRA-LITE 1x12 BASS CABINETS
Our most compact Subway Cabinet, the 1x12 Ultra-Lite combines finely-tuned porting, Top-grade ply, aircraft-style bracing, a super-responsive and efficient neodymium 12” Driver and our musical sounding HF Driver to create an amazing compact Bass cabinet that can handle smaller venues surprisingly well by itself, or combined with another 1x12, a 1x15 or larger format cabinets of different speaker sizes for coverage and flavor, always minding proper impedance loading and/or matching of course, for a multi-dimensional Cabinet array.
General Information |
|
|---|---|
| Build Location | Petaluma, CA USA with the World's Finest Materials |
| Cabinet Material | Light-Weight Italian Poplar |
| Standard Finish Options | Choice of Black Bronco or Black Taurus Vinyl with Black Metal Grille |
| Corner Material | Lexan |
| Custom Finish Options | See Custom Finish Gallery |
Features and Specifications |
|
|---|---|
| Style/Type | Tuned Front Ported Tri-Porting™ |
| Speaker(s) & Mounting Position | Subway Neodymium Speaker |
| High Frequency Horn | Yes |
| Horn Control | Premium Attenuator |
| Input/Output Connectors | 2 x SpeakOn-1/4" (NL-4 combo) |
| Nominal Impedance | 8 ohms (only) |
| Minimum Impedance @ Frequency | 7.45 ohms (@ 50.8 Hz) |
| Average Sensitivity (RMS) 50Hz-1000Hz | 97.5dB/1W/1M |
| Maximum SPL - 50Hz-1000Hz | 124dB/1M |
| Average Thermal Power (RMS) 50Hz-1000Hz | 400 Watts |
| Average Mechanical Power (RMS) 50Hz-1000Hz | 400 Watts |
| Minimum Mechanical Power (RMS) @ Frequency | 385 Watts (@ 74.3Hz) |
| Low Freq F3 (Hz) | 57.5 Hz |
| Low Freq F6 (Hz) | 48.1 Hz |
| Low Freq F10 (Hz) | 41.5 Hz |
| High Freq Response | >12kHz |
| Casters | Optional (sold separately) - Track-Loc™ Removable Casters |
| Additional Features | Optional/Convertible Vertical Cabinet Orientation |
Accessories |
|
|---|---|
| Slip Cover | Included - Fitted Slip Cover |
Weight And Dimensions |
|
|---|---|
| Weight | 32.9 Lbs. |
| Height | 15 1/4" |
| Width | 19 1/4" |
| Depth | 18 1/4" |
Available Formats
DISCLAIMER: In the interest of continuous improvement, all specifications are subject to change without notice. To guarantee correct fit on custom ordered cases & covers, MESA recommends that customers make personal measurements of their product, after they have been received. MESA provides these measurements as a general reference only, without guarantee or liability.
